No.

Items

Unit

Specification

G.652D

1

Mode Field Diameter

1310nm

um

9.2±0.4

1550nm

um

10.4±0.5

2

Cladding Diameter

um

125±0.7

3

Cladding Non-Circularity

%

≤1.0

4

Core-Cladding Concentricity Error

um

≤0.5

5

Coating Diameter

um

245±5

6

Coating Non-circularity

%

≤6.0

7

Cladding-Coating Concentricity Error

um

≤12.0

8

Cable Cutoff Wavelength

nm

λ_c ≤1260

9

Attenuation(max.)

1310nm

dB/km

≤0.4

1550nm

dB/km

≤0.3

Items

Specification

Fiber Count

96

Colored Coating Fiber

Dimension

250±15um

Color

Blue, Orange, Green, Brown, Gray, White, Red, Black, Yellow, Purple, Pink,Aqua

Cable Subunit

Dimension

2.9±0.1mm

Material

LSZH

Color

Yellow(1)(2)...(8)

Strength Member

Kevlar

Central Strength Member

FRP

Dimension

13.0±0.5mm

Material

LSZH

Color

Yellow

Items

Unit

Specification

Tensile (Long Term)

N

300

Tensile (Short Term)

N

600

Crush( Long Term)

N/10cm

300

Crush (Short Term)

N/10cm

1000

Min. Bend Radius (Dynamic)

mm

20D

Min. Bend Radius (Static)

mm

10D

Installation Temperature

℃

-20~+60

Storage Temperature

℃

-40~+70

Operating Temperature

℃

-40~+70
